1-794306-1

Headers, Male Pins Overview

The 1-794306-1 is a vertical PCB pin header from the AMP-DUAC series by TE Connectivity. It features 2 positions in a single row with a 5.08 mm pitch. The connector utilizes through-hole solder termination and phosphor bronze contacts plated with tin. Rated for 600 VAC and 13 A, it employs a polyamide (PA) housing classified under UL 94 V-0 for flame resistance. The shrouded four-wall design ensures secure mating alignment.

Headers, Male Pins Feature Summary

• Shrouded four-wall housing design for precise alignment
• Through-hole solder termination for robust board attachment
• High current and voltage rating capabilities

Headers, Male Pins Applications

• Industrial control systems
• Power distribution units
• General purpose electronic equipment

Headers, Male Pins Procurement Notes

Verify the specific AMP-DUAC series designation and 5.08 mm pitch against official datasheets to ensure compatibility with mating sockets. Confirm that the through-hole solder termination method aligns with your assembly process requirements. Check for RoHS compliance status and UL certification details relevant to your target market regulations before finalizing procurement decisions.

Headers, Male Pins Selection Notes

Select this component when a high-current, vertically mounted header is required for power or signal transmission. The 5.08 mm pitch accommodates larger wire gauges compared to standard signal headers. Ensure the mating socket matches the single-row, two-position configuration and shrouded style to maintain proper electrical isolation and mechanical stability within the enclosure.

Headers, Male Pins Part Context

This part belongs to the AMP-DUAC series, designed for demanding applications requiring reliable power connections. Unlike the MATE-N-LOK series which often uses crimp contacts, this DUAC variant focuses on direct board mounting. It serves as a critical interface point in assemblies where space efficiency and high amperage capacity are prioritized over dense signal packing.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Direct replacement requires matching the exact 5.08 mm pitch, 2-position count, and shrouded header style. Verify housing material and flammability ratings if substituting with generic equivalents.
