1-794680-0

Headers, Male Pins Overview

The 1-794680-0 is a vertical pin header connector from the MATE-N-LOK series manufactured by TE Connectivity AMP Connectors. It features a 10-position configuration with a 3mm pitch, designed for through-hole PCB mounting. The housing is constructed from black nylon with a UL 94 V-0 flammability rating. Contacts are male pins suitable for general electronic applications.

Headers, Male Pins Feature Summary

• Vertical board-to-wire connection architecture
• Secure mechanical locking via slide-lock mechanism
• High-temperature resistant thermoplastic housing

Headers, Male Pins Applications

• Computer peripheral equipment interconnects
• Business machine signal routing
• Appliance control panel connections

Headers, Male Pins Procurement Notes

Verify the specific suffix and contact plating against the official datasheet to ensure compatibility with mating connectors. Confirm that the 3mm pitch and 10-position count match the target PCB footprint requirements before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a robust, high-current capable header is required for vertical mounting. Ensure the mating socket utilizes the same MATE-N-LOK slide-lock system. Verify wire gauge compatibility with the terminal current ratings specified in the technical documentation.

Headers, Male Pins Part Context

This part belongs to the MATE-N-LOK family, known for reliable power and signal transmission in industrial and commercial environments. It represents a standard solution for connecting cables to printed circuit boards where secure retention and ease of assembly are prioritized.

Headers, Male Pins Replacement Considerations

Cross-reference with other 10-position MATE-N-LOK headers. Ensure identical pitch, locking style, and contact orientation. Verify that any substitute meets the same UL flammability and temperature standards.
