1-794682-2

Headers, Male Pins Overview

The 1-794682-2 is a Micro MATE-N-LOK series pin and socket connector manufactured by TE Connectivity AMP Connectors. It features a 4-position, 2-row header with male pin contacts designed for through-hole PCB mounting. The connector utilizes a nylon housing and brass contacts with gold plating. It supports a voltage rating of 250 V and a current rating of 5 A. The pitch is 3 mm, and the insulation material meets UL 94 V-0 flammability standards.

Headers, Male Pins Feature Summary

• Micro MATE-N-LOK series design for reliable board-to-wire interconnects
• Gold-plated brass contacts ensure stable electrical performance
• Nylon housing provides structural integrity and UL 94 V-0 flame resistance

Headers, Male Pins Applications

• General purpose electronic equipment
• Industrial control systems
• Consumer electronics assemblies

Headers, Male Pins Procurement Notes

Verify component authenticity through authorized TE Connectivity channels or certified distributors. Confirm RoHS compliance status and specific lot traceability requirements against project specifications. Ensure storage conditions maintain contact integrity prior to assembly.

Headers, Male Pins Selection Notes

Select this component for applications requiring a compact 4-position connection with robust mechanical locking. The 3 mm pitch suits dense PCB layouts. Verify that the 5 A current rating aligns with circuit load requirements and that through-hole mounting fits the board design constraints.

Headers, Male Pins Part Context

This part belongs to the Micro MATE-N-LOK family, an evolution of the original MATE-N-LOK system. It offers a smaller form factor while maintaining the secure pin-locking mechanism characteristic of the brand. The series is widely used in various industrial and commercial sectors for durable connections.

Headers, Male Pins Replacement Considerations

Consult official TE Connectivity documentation for direct substitutes. Cross-reference compatible housings and contacts within the same Micro MATE-N-LOK series to ensure mechanical and electrical compatibility.
