1-794682-8

Headers, Male Pins Overview

The TE Connectivity AMP Connectors part number 1-794682-8 is a vertical pin header connector belonging to the Micro MATE-N-LOK series. It features an 8-position configuration with a 3mm (0.118 inch) mating pitch and a 3mm row spacing. The connector utilizes two rows of square male pins designed for through-hole termination on printed circuit boards. The housing is constructed from black polyamide (PA, nylon) insulation rated UL94 V-0 for flammability. Contact surfaces are finished with gold or gold-palladium plating to ensure reliable electrical performance.

Headers, Male Pins Feature Summary

• Micro MATE-N-LOK series design provides secure board-to-cable or wire interconnection
• Shrouded four-wall housing structure ensures proper alignment during mating
• Gold or gold-palladium contact plating supports consistent signal integrity
• Through-hole termination method facilitates stable PCB mounting

Headers, Male Pins Applications

• Computer systems and peripheral equipment integration
• Business machine internal wiring connections
• Entertainment center component interfacing
• Appliance control board signal transmission

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to confirm exact contact plating specifications and packaging format. Ensure compatibility with mating socket connectors within the same Micro MATE-N-LOK family. Confirm that the through-hole footprint matches the target PCB design requirements. Check current availability status as manufacturing statuses may change without notice.

Headers, Male Pins Selection Notes

Select this component when a robust, shrouded header with high-current capability is required for industrial or commercial applications. The 3mm pitch allows for wider trace spacing compared to finer pitches. Consider the operating temperature range and voltage rating against system demands. Evaluate mechanical retention needs for the through-hole installation process.

Headers, Male Pins Part Context

This connector is part of the extensive Micro MATE-N-LOK product line manufactured by TE Connectivity AMP Connectors. The series is widely recognized for its durability and versatility in general-purpose electronic interconnects. It represents a standard solution for connecting wires and cables to rigid circuit boards in various electronic assemblies.

Headers, Male Pins Replacement Considerations

Direct substitute part numbers include 3-794682-8 and 4-794682-8 from TE Connectivity AMP Connectors. Verify pin count and pitch dimensions before substitution. Ensure mating interface compatibility with existing cable assemblies.
