Headers, Male Pins Overview

The Molex 1724470610 is a Mini-Fit Versa Color header connector featuring a 4.2 mm pitch and two rows of contacts. It provides ten positions with a 600V AC/DC voltage rating and a maximum current capacity of 13.5A per contact. The component utilizes tin-plated brass terminals for reliable signal transmission. Designed for PCB mounting, it operates within a temperature range of -40°C to +105°C. The housing is constructed from nylon with a UL 94 V-0 flammability rating and is available in blue color options.

Headers, Male Pins Feature Summary

• Dual-row male pin configuration for secure board-to-wire connections
• Color-coded housing design for simplified circuit identification
• Robust nylon insulation ensuring high dielectric strength and thermal stability

Headers, Male Pins Applications

• General purpose electronic assemblies
• Industrial control systems
• Telecommunications equipment

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to confirm terminal plating thickness and housing color variants. Ensure compatibility with mating receptacles from the same Mini-Fit Versa series. Confirm RoHS compliance status through official manufacturer documentation before integration into regulated projects.

Headers, Male Pins Selection Notes

Select this component for applications requiring high voltage isolation and moderate current handling. The 4.2mm pitch accommodates larger wire gauges compared to standard headers. Consider the dual-row layout for space-constrained designs needing increased pin density without increasing footprint dimensions.

Headers, Male Pins Part Context

This part belongs to the Mini-Fit Versa Color series, which offers various circuit counts ranging from two to twelve positions. The series is characterized by its distinct color-coding system and robust mechanical locking features. It serves as a versatile solution for power and signal distribution in diverse industrial environments.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 4.2mm pitch, 10-position count, and dual-row configuration. Verify that alternative headers maintain identical voltage ratings and current capacities. Ensure physical compatibility with existing PCB footprints and mating connectors.
