1AA12-P4-I5-M

1AA12-P4-I5-M is listed in the DC DC Converters range at ChipApex. The manufacturer field lists ULTRAVOLT / Advanced Energy. Its product description is DC DC CONVERTER 1000V 4W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for 1AA12-P4-I5-M

• Description：DC DC CONVERTER 1000V 4W
• Series：UltraVolt® AA
• Mfr：ULTRAVOLT / Advanced Energy
• Package：Box
• Type：High Voltage - Non-Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：11V
• Voltage - Input (Max)：16V
• Voltage - Output 1：1000V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：4mA
• Power (Watts)：4 W
• Applications：ITE (Commercial)
• Features：SCP
• Operating Temperature：-40°C ~ 65°C
• Efficiency：-
• Mounting Type：Through Hole
• Package / Case：11-DIP Module
• Size / Dimension：3.00" L x 1.53" W x 0.78" H (76.2mm x 38.9mm x 19.9mm)
• Supplier Device Package：-
• Control Features：Enable, Active High
• Approval Agency：CE, cURus
• Standard Number：-
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for 1AA12-P4-I5-M
