200SXC120MEFC20X20

200SXC120MEFC20X20 is listed in the Aluminum Electrolytic Capacitors range at ChipApex. The manufacturer field lists Rubycon. Its product description is CAP ALUM 120UF 20% 200V SNAP TH. Review the specifications below when checking this part for your BOM.

Aluminum Electrolytic Capacitors specifications for 200SXC120MEFC20X20

• Description：CAP ALUM 120UF 20% 200V SNAP TH
• Series：SXC
• Mfr：Rubycon
• Package：Bulk
• Capacitance：120 µF
• Tolerance：±20%
• Voltage - Rated：200 V
• ESR (Equivalent Series Resistance)：-
• Lifetime @ Temp.：2000 Hrs @ 105°C
• Operating Temperature：-25°C ~ 105°C
• Polarization：Polar
• Ratings：-
• Applications：General Purpose
• Ripple Current @ Low Frequency：520 mA @ 120 Hz
• Ripple Current @ High Frequency：613.6 mA @ 10 kHz
• Lead Spacing：0.394" (10.00mm)
• Size / Dimension：0.787" Dia (20.00mm)
• Height - Seated (Max)：0.866" (22.00mm)
• Surface Mount Land Size：-
• Mounting Type：Through Hole
• Package / Case：Radial, Can - Snap-In
• Impedance：-

Aluminum Electrolytic Capacitors datasheet and documents for 200SXC120MEFC20X20
