20525-020E-02

Headers, Receptacles, Female Sockets Overview

The I-PEX 20525-020E-02 is a CABLINE®-CA series receptacle connector featuring 20 positions with a 0.40mm pitch. It utilizes surface mount, right-angle termination for board-to-cable applications. The contacts are gold-plated phosphor bronze housed in black LCP insulation rated UL94 V-0. Operating temperature ranges from -40°C to 85°C with a 100VAC rating.

Headers, Receptacles, Female Sockets Feature Summary

• Supports high-speed signal transmission for eDP and MIPI interfaces
• Utilizes micro-coaxial or discrete cable compatibility
• Features mechanical locking structure for secure connection

Headers, Receptacles, Female Sockets Applications

• Notebook and tablet display connections
• AR/VR headset internal flexible ribbon links
• Drone and robot camera module data transmission

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific pin count variant against project requirements, as the CABLINE-CA series includes multiple position options. Confirm that the selected model matches the required right-angle surface mount orientation and micro-coaxial cable specifications. Ensure compliance with RoHS standards and MSL level 1 handling procedures during assembly.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when designing space-constrained portable electronics requiring reliable high-bandwidth video or sensor data transfer. The 0.40mm pitch allows for dense PCB layouts suitable for thin devices. Consider the mechanical latch design if vibration resistance is critical for the target application environment.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the CABLINE®-CA family of ultra-fine pitch connectors designed for high-speed digital signals. The series addresses the industry demand for miniaturization while maintaining signal integrity in mobile and industrial computing platforms. It serves as a standard interconnect solution for modern compact electronic architectures.

Headers, Receptacles, Female Sockets Replacement Considerations

Direct substitutes include other CABLINE-CA variants such as 20525-030E-02 or 20525-050E-02, provided the pin count difference is acceptable for the circuit design. Verify mating cable dimensions and housing geometry before substitution.
