2096206

Overview

The SICK model 2096206 is a safety light curtain component designed for personnel protection in industrial environments. It operates with a resolution of 30 mm and provides a vertical detection field height of 1400 mm. The device supports up to 18 beams and features an external equipment monitoring (EDM) function for enhanced safety integrity. It utilizes a M12, 8-pin male connector for electrical interfacing and is rated IP65/IP67 for environmental protection.

Feature Summary

• Provides personnel protection through precise object detection within the monitored zone
• Integrates external equipment monitoring to verify the functional state of downstream safety components
• Features beam encoding technology to prevent interference from adjacent safety devices
• Designed for robust operation in industrial settings with high ingress protection ratings

Applications

• Protection of hazardous areas around automated machinery
• Safety guarding for press brakes and injection molding machines
• Personnel access monitoring at robotic work cells
• Perimeter protection for automated guided vehicle paths

Procurement Notes

Verify that the specific订货代号 matches the required resolution and height configuration. Confirm compatibility with the corresponding emitter or receiver unit if this is a partial set. Ensure the M12 connector type aligns with existing cabling infrastructure. Check for any regional certification requirements such as CE or UL marking relevant to your installation location.

Selection Notes

Select this model based on the required safety distance and resolution needed for the specific hazard. Consider the mounting orientation and available space for the 1400 mm detection height. Evaluate the need for EDM functionality versus simpler configurations. Ensure the operating voltage and signal output types match the control system interface.

Part Context

This component belongs to SICK's safety light curtain series, which are widely used for machine safety. These devices typically consist of paired emitters and receivers that create a protective field. The 2096206 variant is part of a modular system allowing for various heights and resolutions to suit different machine sizes and risk assessments.

Replacement Considerations

Public confirmed substitute part numbers: None identified.
