2147210050

Headers, Receptacles, Female Sockets Overview

The Molex 2147210050 is a Zero-Hachi series header receptacle featuring a 0.80mm pitch and five positions. It utilizes a right-angle, surface-mount termination style with matte tin plating on the contacts. The connector is rated for 30V maximum voltage and 1.5A per contact current. Operating temperature range spans from -40°C to +85°C. The design incorporates friction lock features for secure mating and includes dual-point contact technology to enhance electrical reliability during operation.

Headers, Receptacles, Female Sockets Feature Summary

• Zero-Hachi system provides robust PCB retention with fitting features
• Dual-point contact feature enhances electrical reliability during operation
• Friction lock mechanism ensures secure mating connection

Headers, Receptacles, Female Sockets Applications

• Compact consumer electronics
• Telecommunications equipment
• Low to medium power applications

Headers, Receptacles, Female Sockets Procurement Notes

Verify that the specific part number matches the required zero-hachi series specifications. Confirm the surface mount orientation and pin count align with the target PCB layout. Ensure compatibility with the intended mating header regarding voltage and current ratings. Check for any specific packaging requirements if applicable to the assembly process.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when board space is heavily constrained due to its ultra-fine pitch design. It is suitable for applications requiring reliable signal transmission in compact devices. Consider the right-angle form factor for specific board stacking or routing needs. Verify that the operating temperature range meets the environmental requirements of the final product.

Headers, Receptacles, Female Sockets Part Context

This component belongs to the Molex Zero-Hachi series, known for ultra-fine pitch interconnects. The series is designed for high-density applications where space is limited. It represents a solution for miniaturization in modern electronic devices while maintaining signal integrity and mechanical stability through specialized contact designs.

Headers, Receptacles, Female Sockets Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Consult official Molex resources for potential cross-references or alternative series within the same product family.
