Description：CONN EDGE DUAL FMALE 6POS 0.200
Series：243
Mfr：EDAC Inc.
Package：Bulk

SKU:6041cca97bd8 Category: Edgeboard Connectors Brand: EDAC Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

243-006-542-201 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists EDAC Inc.. Its product description is CONN EDGE DUAL FMALE 6POS 0.200. Review the specifications below when checking this part for your BOM.

Edgeboard Connectors specifications for 243-006-542-201

Description：CONN EDGE DUAL FMALE 6POS 0.200
Series：243
Mfr：EDAC Inc.
Package：Bulk
Card Type：Non Specified - Dual Edge
Gender：Female
Number of Positions/Bay/Row：3
Number of Positions：6
Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
Number of Rows：2
Pitch：0.200" (5.08mm)
Read Out：Dual
Features：-
Mounting Type：Through Hole
Termination：Solder Eyelet(s)
Contact Material：Copper Alloy
Contact Finish：Gold
Contact Finish Thickness：-
Contact Type：Cantilever
Color：White
Flange Feature：-
Operating Temperature：-40°C ~ 105°C

Edgeboard Connectors datasheet and documents for 243-006-542-201

243-006-542-201

Edgeboard Connectors Overview

The EDAC 243-006-542-201 is a standard card edge connector receptacle featuring six positions with a 5.08 mm pitch. Designed for dual-edge non-specified card types, it utilizes gold-plated copper alloy contacts to ensure reliable signal transmission. The housing is constructed from white thermoplastic material, providing structural integrity and insulation. This component supports panel mount installation and is rated for a current capacity of 5 A per contact. It is engineered for vertical orientation applications requiring robust mechanical connection between the board and the connector.

Edgeboard Connectors Feature Summary

Dual-edge configuration accommodates non-specified card edge types for versatile integration
Gold-plated contacts provide corrosion resistance and stable electrical performance
Panel mount design ensures secure mechanical attachment in enclosed environments

Edgeboard Connectors Applications

Industrial control system interconnections
Telecommunications equipment backplanes
Test and measurement instrument interfaces

Edgeboard Connectors Procurement Notes

Verify that the specific part number matches the required dual-edge card specification. Confirm that the 5.08 mm pitch aligns with the target PCB or card dimensions. Ensure the panel mount style suits the enclosure design constraints. Check for any updated environmental compliance certifications if required by the final application standards.

Edgeboard Connectors Selection Notes

Select this connector when a dual-edge card interface with a 5.08 mm pitch is required. The 6-position count fits applications needing limited I/O lines. The gold plating is suitable for environments where oxidation resistance is critical. Consider the panel mount requirement as a fixed constraint for this specific model.

Edgeboard Connectors Part Context

This component belongs to the EDAC standard card edge connector series. It represents a specialized solution for dual-edge card connections, differing from single-edge variants. The 243 series designation indicates specific dimensional and electrical characteristics tailored for industrial-grade connectivity requirements.
