3-1775801-6

Edgeboard Connectors Overview

The TE Connectivity AMP Connectors part number 3-1775801-6 is a PCI Express female card edge connector. It features 98 positions with a 0.039-inch (1.00mm) pitch. The housing is black and designed for surface mount termination. This component supports PCI Express 3.1 specifications and includes a 30-inch gold plating finish on the contacts to ensure reliable signal transmission in high-speed data applications.

Edgeboard Connectors Feature Summary

• Supports PCI Express 3.1 interface standards for high-speed data transfer
• Features 98-position female contact configuration
• Utilizes 0.039-inch (1.00mm) pitch for compact board integration
• Includes 30-inch gold plating for enhanced conductivity and corrosion resistance

Edgeboard Connectors Applications

• High-performance computing systems requiring PCIe 3.1 connectivity
• Server backplanes and storage arrays
• Industrial automation control boards
• Telecommunications infrastructure equipment

Edgeboard Connectors Procurement Notes

Verify that the specific order matches the 98-position count and 1.00mm pitch requirements. Confirm the surface mount termination style aligns with the PCB design. Ensure the black housing color and 30-inch gold plating specification are accepted for the intended application environment. Check for RoHS compliance status if required by project regulations.

Edgeboard Connectors Selection Notes

Select this connector when a 98-position female interface is required for PCI Express 3.1 compliant designs. The 1.00mm pitch allows for dense routing on limited board space. Surface mount termination is suitable for automated assembly processes. Consider the mechanical retention needs of the card edge connection during system integration.

Edgeboard Connectors Part Context

This component belongs to the PCI Express connector family from TE Connectivity AMP Connectors. It is engineered to meet industry standards for high-speed serial interconnects. The design focuses on signal integrity and mechanical durability for demanding electronic environments.

Edgeboard Connectors Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Verify compatibility with existing mating cards before considering alternative sources.
