302-006-256-201

$2.94

Description：302 SERIES (.05" (1.27MM) CONTAC
Series：302
Mfr：EDAC Inc.
Package：Tube

SKU:373c194f6114 Category: Edgeboard Connectors Brand: EDAC Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

302-006-256-201 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists EDAC Inc.. Its product description is 302 SERIES (.05" (1.27MM) CONTAC. Review the specifications below when checking this part for your BOM.

Edgeboard Connectors specifications for 302-006-256-201

Description：302 SERIES (.05" (1.27MM) CONTAC
Series：302
Mfr：EDAC Inc.
Package：Tube
Card Type：Non Specified - Dual Edge
Gender：Female
Number of Positions/Bay/Row：3
Number of Positions：6
Card Thickness：0.051" ~ 0.071" (1.30mm ~ 1.80mm)
Number of Rows：2
Pitch：0.050" (1.27mm)
Read Out：Dual
Features：-
Mounting Type：Board Edge, Straddle Mount
Termination：Solder
Contact Material：Copper Alloy
Contact Finish：Gold
Contact Finish Thickness：Flash
Contact Type：Cantilever
Color：Black
Flange Feature：-
Operating Temperature：-55°C ~ 85°C

Edgeboard Connectors datasheet and documents for 302-006-256-201

302-006-256-201

Edgeboard Connectors Overview

The EDAC Inc. 302-006-256-201 is a standard card edge connector from the 302 series, designed for dual-edge female connections. It features six positions with a contact spacing of 0.050 inches (1.27mm). The contacts are gold flash plated copper alloy with a cantilever type design. The housing is black polyamide (PA66) and lacks mounting lugs. It supports board thicknesses between 0.051 and 0.071 inches (1.30mm to 1.80mm) and operates within a temperature range of -55°C to 85°C.

Edgeboard Connectors Feature Summary

Cantilever contact design ensures reliable electrical connection for dual-edge cards
Gold flash plating provides corrosion resistance and low contact resistance
Polyamide housing offers durable insulation without integrated mounting lugs

Edgeboard Connectors Applications

Industrial control systems requiring compact interconnects
Medical equipment utilizing EDAC medical interconnect solutions
Consumer electronics with limited space constraints

Edgeboard Connectors Procurement Notes

Verify availability status as supply may be restricted in certain regions. Confirm that the specific ordering suffix matches the required contact finish and housing configuration. Ensure compatibility with the target PCB layout regarding the absence of mounting lugs. Cross-reference the manufacturer part number against authorized distributor lists to avoid counterfeit components.

Edgeboard Connectors Selection Notes

Select this component when a low-profile, dual-edge female connector with fine pitch is required. The 0.050-inch spacing suits high-density applications. Consider the lack of mounting lugs if mechanical stability via other means is needed. Verify that the operating temperature range meets the environmental requirements of the end application.

Edgeboard Connectors Part Context

This part belongs to the EDAC 302 series, which specializes in standard card edge connectors. The series is characterized by its fine 0.050-inch contact spacing and robust construction. EDAC provides these connectors for various sectors including industrial, medical, and consumer markets, emphasizing reliability and precision in interconnect solutions.
