305-012-520-204

Edgeboard Connectors Overview

The EDAC Inc. 305-012-520-204 is a standard card edge connector header featuring 12 positions with a 3.96 mm pitch. Designed for panel mounting at a vertical angle, it accommodates a board thickness of 1.57 mm. The contacts are constructed from copper alloy and gold-plated to ensure reliable signal transmission. Rated for 5 A current, the unit utilizes solder pin termination for secure PCB attachment.

Edgeboard Connectors Feature Summary

• Dual female contact configuration for robust card edge engagement
• Gold-plated copper alloy contacts for enhanced conductivity and corrosion resistance
• Vertical panel mount style facilitates structured system integration

Edgeboard Connectors Applications

• Industrial control systems requiring modular interface connections
• Communication equipment utilizing standardized card edge interfaces
• Automotive electronics assemblies needing reliable vertical headers

Edgeboard Connectors Procurement Notes

Verify the specific suffix codes against official EDAC documentation to confirm exact plating thickness and material specifications. Ensure compatibility with the target card edge thickness of 1.57 mm before finalizing procurement orders to prevent mechanical fit issues.

Edgeboard Connectors Selection Notes

Select this component when a 12-position vertical header is required for panel-mounted applications. Confirm that the 3.96 mm pitch aligns with the mating card edge design. Verify that the 5 A current rating meets the electrical requirements of the specific circuit application.

Edgeboard Connectors Part Context

This part belongs to the EDAC 305 series of standard card edge connectors. The series offers various position counts and mounting styles. The 305-012-520-204 specifically provides a compact 12-position solution for vertical panel mounting scenarios within industrial and commercial electronic assemblies.

Edgeboard Connectors Replacement Considerations

Cross-reference with other EDAC 305 series parts for alternative position counts. Verify mechanical dimensions and electrical ratings against competitors like Samtec or Molex if sourcing alternatives. Ensure mating card edge specifications match exactly.
