Description：CONN EDGE DUAL FMALE 12POS 0.156
Series：305
Mfr：EDAC Inc.
Package：Box

SKU:7d5d86e0e48e Category: Edgeboard Connectors Brand: EDAC Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

305-012-520-502 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists EDAC Inc.. Its product description is CONN EDGE DUAL FMALE 12POS 0.156. Review the specifications below when checking this part for your BOM.

Edgeboard Connectors specifications for 305-012-520-502

Description：CONN EDGE DUAL FMALE 12POS 0.156
Series：305
Mfr：EDAC Inc.
Package：Box
Card Type：Non Specified - Dual Edge
Gender：Female
Number of Positions/Bay/Row：6
Number of Positions：12
Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
Number of Rows：2
Pitch：0.156" (3.96mm)
Read Out：Dual
Features：-
Mounting Type：Panel Mount, Through Hole
Termination：Solder
Contact Material：Copper Alloy
Contact Finish：Gold
Contact Finish Thickness：10.0µin (0.25µm)
Contact Type：Semi Bellows
Color：Green
Flange Feature：Flush Mount, Top Opening, Unthreaded, 0.128" (3.25mm) Dia
Operating Temperature：-40°C ~ 105°C

Edgeboard Connectors datasheet and documents for 305-012-520-502

305-012-520-502

Edgeboard Connectors Overview

The EDAC Inc. 305-012-520-502 is a standard card edge connector from the 305 series, designed for dual-edge board insertion. It features 12 positions with a 3.96 mm (0.156 inch) pitch and supports a maximum PCB thickness of 1.57 mm. The contacts are made of copper alloy with gold plating to ensure reliable signal transmission. Rated for 5 A continuous current, this vertical panel-mount header utilizes solder lug termination for secure attachment.

Edgeboard Connectors Feature Summary

Accepts between-contact and in-contact polarizing keys for precise alignment
Dual-edge design accommodates specific board insertion requirements
Gold-plated copper alloy contacts provide durable electrical connectivity

Edgeboard Connectors Applications

Industrial control systems requiring polarized connections
Communication equipment interface modules
Automotive electronic subsystems

Edgeboard Connectors Procurement Notes

Verify the exact suffix configuration against official EDAC documentation before ordering, as minor variations may exist. Confirm that the target application requires the specific 3.96 mm pitch and 12-position count. Ensure compatibility with the intended PCB thickness and polarizing key style. Cross-reference the manufacturer's latest datasheet to confirm material specifications and environmental ratings match project requirements.

Edgeboard Connectors Selection Notes

Select this component when a dual-edge card edge connector with a 3.96 mm pitch is required. The 12-position layout suits applications needing moderate I/O density. Verify that the panel-mount vertical orientation fits the enclosure constraints. Ensure the system can accommodate the necessary polarizing keys for proper mating alignment.

Edgeboard Connectors Part Context

This part belongs to the EDAC 305 series of standard card edge connectors. The series is characterized by its robust construction and compatibility with various polarizing key styles. These connectors are engineered for high-reliability applications where secure board retention and consistent electrical performance are critical.
