Edgeboard Connectors Overview

The EDAC Inc. 305-014-521-501 is a dual-row card edge connector designed for through-hole mounting. It features 14 positions with a 0.156-inch (3.96 mm) pitch and accepts board thicknesses ranging from 0.054 to 0.070 inches. The contacts are semi-bellows type made of copper alloy with gold plating, ensuring reliable electrical performance. The housing is constructed from green thermoplastic polyester, supporting an operating temperature range of -40°C to 105°C.

Edgeboard Connectors Feature Summary

• Dual-row configuration for high-density signal routing
• Semi-bellows contact design for secure board retention
• Gold-plated copper alloy contacts for corrosion resistance
• Thermoplastic polyester insulation for thermal stability

Edgeboard Connectors Applications

• Industrial control system backplanes
• Telecommunications equipment interconnects
• Consumer electronics motherboard connections

Edgeboard Connectors Procurement Notes

Verify the specific suffix codes against the manufacturer's ordering guide to ensure correct pin count and termination style. Confirm RoHS compliance status if required by project specifications. Cross-reference the part number with official distributor catalogs to validate current availability and standard packaging quantities before finalizing procurement orders.

Edgeboard Connectors Selection Notes

Select this component when a dual-row, through-hole card edge connector is required for boards within the specified thickness tolerance. Ensure the mating card edge width matches the 0.156-inch pitch constraint. Consider the operating temperature range and material compatibility with adjacent components during mechanical assembly planning.

Edgeboard Connectors Part Context

This part belongs to the EDAC 305 series, which offers various mounting options and position counts. The series is characterized by its robust construction and standardized dimensions, facilitating integration into legacy and modern electronic systems requiring reliable vertical or panel-mounted interconnections.

Edgeboard Connectors Replacement Considerations

Consult the EDAC 305 Series Ordering Guide for direct substitutes with differing pin counts or termination styles. Verify mechanical fit and electrical continuity before replacing with generic equivalents.
