Edgeboard Connectors Overview

The EDAC Inc. 305-014-556-203 is a standard card edge connector from the 305 series, designed for dual-edge board applications. It features 14 positions with a 3.96 mm (0.156 inch) pitch. The connector utilizes gold-plated copper alloy contacts and solder pin termination. It supports PCB thicknesses of 1.37 mm to 1.78 mm and operates within a temperature range of -40°C to +105°C.

Edgeboard Connectors Feature Summary

• Dual-edge female connector design for non-specified card types
• Gold-plated copper alloy contacts for reliable signal transmission
• Solder pin termination for secure panel or PCB mounting

Edgeboard Connectors Applications

• Industrial control systems requiring robust edge connections
• Telecommunications equipment interface modules
• Test and measurement instrument backplanes

Edgeboard Connectors Procurement Notes

Verify the specific suffix codes against the official EDAC datasheet to confirm exact plating thickness and material specifications. Ensure compatibility with the target card edge thickness range of 1.37 mm to 1.78 mm before procurement. Confirm RoHS compliance status through the manufacturer's current documentation.

Edgeboard Connectors Selection Notes

Select this component when a dual-edge female connector with a 3.96 mm pitch is required. It is suitable for applications needing 14 positions with gold-plated contacts. Consider the operating temperature range and solder termination method for integration into the final assembly design.

Edgeboard Connectors Part Context

This part belongs to the EDAC 305 series of standard card edge connectors. The series offers various position counts and mounting styles. The 305-014-556-203 specifically provides a 14-position configuration with dual-edge compatibility and vertical orientation options.

Edgeboard Connectors Replacement Considerations

Consult the EDAC 305 series ordering guide for direct substitutes with different position counts or mounting styles. Verify mechanical dimensions and electrical ratings match the original design requirements before substitution.
