305-020-520-504

$5.05

Description：CONN EDGE DUAL FMALE 20POS 0.156
Series：305
Mfr：EDAC Inc.
Package：Box

SKU:75119b4d7e3d Category: Edgeboard Connectors Brand: EDAC Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

305-020-520-504 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists EDAC Inc.. Its product description is CONN EDGE DUAL FMALE 20POS 0.156. Review the specifications below when checking this part for your BOM.

Edgeboard Connectors specifications for 305-020-520-504

Description：CONN EDGE DUAL FMALE 20POS 0.156
Series：305
Mfr：EDAC Inc.
Package：Box
Card Type：Non Specified - Dual Edge
Gender：Female
Number of Positions/Bay/Row：10
Number of Positions：20
Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
Number of Rows：2
Pitch：0.156" (3.96mm)
Read Out：Dual
Features：-
Mounting Type：Panel Mount, Through Hole
Termination：Solder
Contact Material：Copper Alloy
Contact Finish：Gold
Contact Finish Thickness：10.0µin (0.25µm)
Contact Type：Semi Bellows
Color：Green
Flange Feature：Flush Mount, Top Opening, Unthreaded, 0.156" (3.96mm) Dia
Operating Temperature：-40°C ~ 105°C

Edgeboard Connectors datasheet and documents for 305-020-520-504

305-020-520-504

Edgeboard Connectors Overview

The EDAC Inc. 305-020-520-504 is a standard card edge connector featuring 20 positions arranged in a dual-row configuration. It utilizes a 3.96 mm (0.156 inch) pitch and is designed for PCB thicknesses of 1.57 mm. The component supports panel mount and through-hole installation with vertical orientation. Contacts are gold-plated copper alloy, rated for 5 A continuous current and 1800 VACrms dielectric strength. Operating temperature ranges from -40°C to +105°C, with an insulation resistance of 5 GOhms.

Edgeboard Connectors Feature Summary

Accepts between-contact and in-contact polarizing keys for secure board retention
Dual-edge female contact design for reliable signal transmission
Gold-plated contacts ensure corrosion resistance and low contact impedance

Edgeboard Connectors Applications

Industrial control systems requiring robust card edge interfaces
Telecommunications equipment utilizing modular board architectures
Automotive electronics demanding high vibration resistance

Edgeboard Connectors Procurement Notes

Verify the specific suffix codes against official EDAC documentation to confirm exact plating thickness, housing material variants, and packaging configurations. Ensure compatibility with existing polarizing key requirements and verify that the 1.57 mm board thickness specification matches the target application's PCB constraints before finalizing procurement orders.

Edgeboard Connectors Selection Notes

Select this model when a dual-row, 20-position interface with a 3.96 mm pitch is required. It is suitable for applications needing panel mounting stability and high dielectric strength. Consider the 5 A current rating and wide temperature range for harsh environments. Verify that the vertical orientation fits within the mechanical enclosure constraints.

Edgeboard Connectors Part Context

This component belongs to the EDAC 305 series of standard card edge connectors. The series offers various position counts and mounting styles. The 305-020-520-504 specifically addresses the need for a 20-position dual-row connector with gold contacts and polarizing key compatibility, fitting into the broader portfolio of industrial-grade interconnect solutions.
