Edgeboard Connectors Overview

The EDAC Inc. 305-060-521-201 is a standard card edge connector receptacle from the 305 Series, designed for PCB mounting. It features 60 positions arranged in a dual row with a 3.96 mm (0.156 inch) pitch. The connector supports board thicknesses of 1.37 mm to 1.78 mm and utilizes gold-plated copper alloy contacts rated for 5 A current. Constructed with thermoplastic polyester insulation, it operates within a temperature range of -40°C to +105°C.

Edgeboard Connectors Feature Summary

• Dual-row configuration providing 60 contact positions for high-density interconnect applications
• Gold-plated copper alloy contacts ensure reliable signal transmission and corrosion resistance
• Thermoplastic polyester housing offers durability and stable electrical insulation properties

Edgeboard Connectors Applications

• Industrial control systems requiring robust card edge interfaces
• Medical equipment utilizing EDAC medical interconnect solutions
• Agricultural technology hardware operating in harsh environments

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix against official EDAC documentation to confirm exact plating thickness, flange characteristics, and termination style. Ensure compatibility with target PCB dimensions and mating card specifications before procurement. Cross-reference manufacturer part numbers with distributor listings to confirm availability and lead times.

Edgeboard Connectors Selection Notes

Select this component when a 60-position dual-row interface is required with a 3.96 mm pitch. Confirm that the mating card thickness falls within the 1.37 mm to 1.78 mm range. Verify that the green thermoplastic polyester housing meets environmental requirements for the intended application temperature range.

Edgeboard Connectors Part Context

This part belongs to the EDAC 305 Series of standard card edge connectors. The series includes various position counts and configurations, such as the 305-072-521-201 and 305-040-521-202 models. These connectors are widely used in industrial and specialized sectors where reliable vertical or panel mounting is necessary.

Edgeboard Connectors Replacement Considerations

Compatible substitutes include other 305 Series variants like 305-072-521-201 or 305-040-521-202, provided the position count and mechanical constraints align with the design requirements.
