305-060-521-278

Edgeboard Connectors Overview

The EDAC Inc. 305-060-521-278 is a dual female card edge connector from the 305 series, designed for panel mount and through-hole termination. It features 60 positions with a 0.156-inch (3.96 mm) pitch across two rows. The contacts are made of copper alloy with gold plating, suitable for non-specified double-sided cards with thicknesses between 0.054 and 0.070 inches. The insulator is green thermoplastic polyester, rated for operation from -40°C to 105°C.

Edgeboard Connectors Feature Summary

• Dual female configuration with gold-plated copper alloy contacts for reliable signal transmission.
• Thermoplastic polyester insulator provides durability within a specified temperature range.
• Panel mount design with through-hole soldering ensures secure mechanical attachment.

Edgeboard Connectors Applications

• Industrial control systems requiring robust interconnects
• Medical equipment interfaces
• Agricultural technology hardware

Edgeboard Connectors Procurement Notes

Verify component authenticity against EDAC Inc. official documentation before integration. Confirm that the specific suffix matches project requirements, as variations may exist within the 305 series. Ensure compliance with RoHS3 standards if environmental regulations apply to the final assembly. Cross-reference the datasheet for precise dimensional tolerances to guarantee fit within the designated enclosure space.

Edgeboard Connectors Selection Notes

Select this model when a high-pin-count, double-sided connection is required with a 3.96 mm pitch. The 60-position capacity supports complex circuit routing in compact panel-mounted designs. Consider the operating temperature range and contact material properties for long-term reliability in demanding environments compared to lower-specification alternatives.

Edgeboard Connectors Part Context

This component belongs to the EDAC 305 series of standard card edge connectors. The series offers various position counts and mounting styles, catering to diverse industrial and commercial applications. The 305-060 variant specifically addresses needs for higher density connections while maintaining the structural integrity typical of the series.

Edgeboard Connectors Replacement Considerations

Consult the EDAC 305, 315, and 355 Series Ordering Guide for potential substitutes. Verify pin count, pitch, and mounting style compatibility before substitution. No direct public substitute part numbers are confirmed for this specific configuration.
