Edgeboard Connectors Overview

The EDAC Inc. 395-070-524-888 is a single-row card edge connector designed for vertical through-hole mounting. It features 70 positions with a 0.100-inch (2.54mm) pitch and accepts board thicknesses ranging from 0.054 to 0.070 inches. The connector utilizes gold-plated cantilever contacts housed in a black thermoplastic polyester body, operating within a temperature range of -40°C to 105°C.

Edgeboard Connectors Feature Summary

• Single-sided female contact configuration
• Gold-plated cantilever spring contacts
• Vertical through-hole termination style

Edgeboard Connectors Applications

• Industrial control systems
• Telecommunications equipment
• Computer peripheral interfaces

Edgeboard Connectors Procurement Notes

Verify the specific suffix '888' against official EDAC documentation to confirm the exact contact finish and insulation material specifications. Ensure the ordering part number matches the required flange characteristics and terminal row count before procurement.

Edgeboard Connectors Selection Notes

Select this component when a single-row, vertical interface is required for boards up to 0.070 inches thick. Confirm that the 0.100-inch pitch aligns with the target PCB layout and that the thermoplastic polyester housing meets environmental requirements.

Edgeboard Connectors Part Context

This component belongs to the EDAC 395 series of standard card edge connectors. The series provides various position counts and termination styles, utilizing consistent 0.100-inch spacing for reliable signal transmission in general-purpose electronic assemblies.

Edgeboard Connectors Replacement Considerations

Compatible substitutes include the EDAC 395-070-524-407 and 395-070-524-208, provided the specific contact plating and flange configurations match the design requirements.
