3986-D12S05LT-1W

3986-D12S05LT-1W is listed in the DC DC Converters range at ChipApex. The manufacturer field lists HenLv Power. Its product description is 1W Fixed DC 12V to DC 5VDC Conve. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for 3986-D12S05LT-1W

• Description：1W Fixed DC 12V to DC 5VDC Conve
• Series：D_S_LT-1W (1W)
• Mfr：HenLv Power
• Package：Tube
• Type：-
• Number of Outputs：1
• Voltage - Input (Min)：11.4V
• Voltage - Input (Max)：12.6V
• Voltage - Output 1：5V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：200mA
• Power (Watts)：1 W
• Voltage - Isolation：3 kV
• Applications：Industrial
• Features：-
• Operating Temperature：-40°C ~ 105°C (With Derating)
• Efficiency：80 ~ 88%
• Mounting Type：Surface Mount
• Package / Case：-
• Size / Dimension：0.50" L x 0.41" W x 0.21" H (12.7mm x 10.4mm x 5.3mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：CE
• Standard Number：62321;62368-1;55032;61000;55035
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for 3986-D12S05LT-1W
