4-1415011-1

4-1415011-1 is listed in the Power Relays, Over 2 Amps range at ChipApex. The manufacturer field lists TE Connectivity Potter & Brumfield Relays. Its product description is RELAY GEN PURPOSE DPDT 10A 125V. Review the specifications below when checking this part for your BOM.

Power Relays, Over 2 Amps specifications for 4-1415011-1

• Description：RELAY GEN PURPOSE DPDT 10A 125V
• Series：MT, SCHRACK
• Mfr：TE Connectivity Potter & Brumfield Relays
• Package：Bulk,Bulk
• Mounting Type：Socketable
• Coil Voltage：125VDC
• Contact Form：DPDT (2 Form C)
• Contact Rating (Current)：10:00 AM
• Switching Voltage：400VAC - Max
• Load - Max Switching：2500VA
• Coil Current：-
• Coil Type：Non Latching
• Features：Test Button
• Termination Style：Plug In, 8 Pin (Octal)
• Seal Rating：-
• Coil Insulation：Class B
• Must Operate Voltage：93.75 VDC
• Must Release Voltage：12.5 VDC
• Operating Temperature：-40°C ~ 60°C
• Contact Material：Silver Nickel (AgNi)
• Approval Agency：cURus, VDE
• Relay Type：General Purpose
• Grade：-
• Qualification：-
• Operate Time：15 ms
• Release Time：10 ms

Power Relays, Over 2 Amps datasheet and documents for 4-1415011-1
