4-1415535-7

4-1415535-7 is listed in the Power Relays, Over 2 Amps range at ChipApex. The manufacturer field lists TE Connectivity Potter & Brumfield Relays. Its product description is RELAY GEN PURPOSE SPST 6A 6V. Review the specifications below when checking this part for your BOM.

Power Relays, Over 2 Amps specifications for 4-1415535-7

• Description：RELAY GEN PURPOSE SPST 6A 6V
• Series：PE, SCHRACK
• Mfr：TE Connectivity Potter & Brumfield Relays
• Package：Bulk
• Mounting Type：Through Hole
• Coil Voltage：6VDC
• Contact Form：SPST-NO (1 Form A)
• Contact Rating (Current)：6:00 AM
• Switching Voltage：400VAC - Max
• Load - Max Switching：2000VA
• Coil Current：34.9 mA
• Coil Type：Non Latching
• Features：-
• Termination Style：PC Pin
• Seal Rating：Sealed - Flux Protection
• Coil Insulation：-
• Must Operate Voltage：4.5 VDC
• Must Release Voltage：0.6 VDC
• Operating Temperature：-40°C ~ 85°C
• Contact Material：Silver Nickel (AgNi)
• Approval Agency：cURus, VDE
• Relay Type：General Purpose
• Grade：-
• Qualification：-
• Operate Time：8 ms
• Release Time：8 ms
