449-10-272-00-560000

Headers, Male Pins Overview

The Mill-Max Manufacturing Corp. part number 449-10-272-00-560000 is a surface mount pin header connector designed for high-reliability interconnect applications. This component features a double-row configuration with a total of 72 positions, providing robust connectivity in compact footprints. The connector utilizes a standard 0.100-inch (2.54mm) pitch to ensure compatibility with industry-standard mating interfaces. It is engineered with .030-inch diameter pins to support stable electrical connections. The surface mount technology facilitates automated assembly processes while maintaining mechanical stability on printed circuit boards.

Headers, Male Pins Feature Summary

• Double-row surface mount architecture for dense board integration
• Precision-machined contact pins ensuring low contact resistance
• Standardized pitch geometry for broad mating compatibility

Headers, Male Pins Applications

• Industrial control system interconnections
• Telecommunications equipment backplanes
• Data center server motherboard connections

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official Mill-Max documentation to confirm plating specifications and material variants. Ensure that the selected variant matches the required thermal and environmental ratings for the target application. Cross-reference the manufacturer's latest catalog to confirm current production status and availability constraints before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a high-density double-row header is required for surface mount assembly. Evaluate the mechanical footprint constraints against the 72-position layout to ensure adequate board space. Consider the .030-inch pin diameter for current carrying capacity requirements relative to the specific circuit design parameters.

Headers, Male Pins Part Context

This part belongs to the Mill-Max 449 series, which specializes in precision-machined interconnect components. The series is recognized for its reliability in demanding environments, including defense and aerospace sectors. Mill-Max manufactures these components using vertical integration strategies to maintain strict quality controls over the machining and finishing processes.

Headers, Male Pins Replacement Considerations

Direct substitutes within the same series may vary by position count or row configuration. Verify exact dimensional tolerances and pin diameters when considering alternative part numbers from the same manufacturer family.
