450-10-220-00-001000

Headers, Male Pins Overview

The Mill-Max 450-10-220-00-001000 is a standard pin header connector designed for through-hole mounting. It features 20 positions with a 0.100-inch (2.54mm) pitch, arranged in a single row. The connector utilizes male pins with a circular contact shape and tin plating on the mating interface. Constructed for board-to-board applications, it includes a push-pull fastening mechanism to secure connections. The housing provides an insulation height of 0.110 inches, while the total contact length measures 0.477 inches. This component is currently active and available in bulk packaging.

Headers, Male Pins Feature Summary

• Through-hole mounting configuration for reliable PCB integration
• Push-pull fastening mechanism for secure connection retention
• Tin-plated male contacts ensuring corrosion resistance

Headers, Male Pins Applications

• Board-to-board interconnect systems
• Standard pin header assemblies
• Electronic device signal routing

Headers, Male Pins Procurement Notes

Verify the specific manufacturer part number against official Mill-Max documentation before procurement. Confirm that the required quantity aligns with the bulk packaging specifications provided by the supplier. Ensure compatibility with existing PCB footprint designs and mating connector requirements. Check for any regional distribution restrictions or special ordering procedures that may apply to this specific series component.

Headers, Male Pins Selection Notes

Select this component when a standard 2.54mm pitch header is required for through-hole assembly. The single-row design suits space-constrained layouts needing 20 connections. Consider the push-pull feature if vibration resistance is necessary. Verify that the tin plating meets environmental and conductivity standards for the intended application environment.

Headers, Male Pins Part Context

This part belongs to the Mill-Max 450 series, which focuses on standard pin headers. The series offers various position counts and configurations for general interconnect needs. The 450-10-220 variant specifically addresses requirements for 20-position connections. It represents a common solution for basic electronic circuit interfacing where reliability and standard dimensions are prioritized.

Headers, Male Pins Replacement Considerations

Consult official Mill-Max cross-reference documents for verified substitute part numbers. Ensure any replacement maintains identical pitch, position count, and mounting style. Verify mechanical compatibility with existing mating connectors and PCB layouts before substitution.
