520C143T400FG2D

520C143T400FG2D is listed in the Aluminum Electrolytic Capacitors range at ChipApex. The manufacturer field lists Cornell Dubilier Knowles. Its product description is CAP ALUM 14000UF 400V SCREW CHAS. Review the specifications below when checking this part for your BOM.

Aluminum Electrolytic Capacitors specifications for 520C143T400FG2D

• Description：CAP ALUM 14000UF 400V SCREW CHAS
• Series：520C
• Mfr：Cornell Dubilier Knowles
• Package：Bulk
• Capacitance：14000 µF
• Tolerance：-10%, +50%
• Voltage - Rated：400 V
• ESR (Equivalent Series Resistance)：13.8mOhm @ 120Hz
• Lifetime @ Temp.：8000 Hrs @ 85°C
• Operating Temperature：-40°C ~ 85°C
• Polarization：Polar
• Ratings：-
• Applications：General Purpose
• Ripple Current @ Low Frequency：28.8 A @ 120 Hz
• Ripple Current @ High Frequency：-
• Lead Spacing：1.250" (31.75mm)
• Size / Dimension：3.500" Dia (88.90mm)
• Height - Seated (Max)：8.687" (220.65mm)
• Surface Mount Land Size：-
• Mounting Type：Chassis Mount
• Package / Case：Radial, Can - Screw Terminals
• Impedance：-

Aluminum Electrolytic Capacitors datasheet and documents for 520C143T400FG2D
