6054273

Overview

The SICK model 6054273 is a safety light curtain component belonging to the M2000 Standard series. It functions as an optical protective device designed for personnel protection in industrial environments. The unit features beam encoding and supports external device monitoring (EDM) for enhanced system integrity. Connection is facilitated via an M12, 8-pin male connector. This specific part number corresponds to a receiver or transmitter module within the M20S/M20E product line, engineered to detect intrusions into hazardous zones through modulated infrared light beams.

Feature Summary

• Beam encoding technology ensures reliable identification of active sensors and prevents interference from ambient light or adjacent units.
• Supports External Device Monitoring (EDM) to verify the functional status of downstream safety relays or contactors.
• Utilizes robust M12 connector interfaces for secure electrical connection and simplified installation.
• Designed for high-resolution detection with narrow beam spacing to ensure precise object detection.

Applications

• Personnel protection at press brakes and stamping machines
• Safety guarding around robotic work cells
• Protection zones for automated assembly lines

Procurement Notes

Verify the exact suffix codes against the official SICK catalog to confirm beam count, resolution, and connector type. Ensure compatibility with existing M2000 controllers and power supplies. Cross-reference ordering numbers with current datasheets to avoid obsolete variants. Confirm environmental ratings match the installation site requirements.

Selection Notes

Select based on required protection height and resolution. Verify that the chosen model supports EDM if integrated with external safety circuits. Check connector type compatibility with existing cabling infrastructure. Ensure the operating range meets the specific machine guard distance requirements.

Part Context

This component is part of the SICK M2000 Standard safety light curtain family. The series is widely used in industrial automation for creating non-contact protective fields. The M2000 line emphasizes modular design and ease of integration into safety networks, serving critical roles in machinery safety compliance.

FAQ

Does this model support External Device Monitoring?

Yes, models in this series typically support EDM to monitor the status of connected safety relays.

What type of connector is used?

The unit utilizes an M12, 8-pin male connector for power and signal transmission.
