60B224C

Fixed Inductors Overview

The Murata Power Solutions 60B224C is a surface mount power inductor from the 6000B series, designed for high current applications. It features an unshielded wirewound construction with an inductance of 220 µH and a tolerance of ±15%. The component supports a maximum DC current of 5 A and has a maximum DC resistance of 50 mΩ. Its self-resonant frequency is 3.21 MHz at a test frequency of 100 kHz. The physical dimensions are 27 mm in length, 23.5 mm in width, and 20 mm in height. It operates within a temperature range of -40°C to +85°C.

Fixed Inductors Feature Summary

• Unshielded wirewound design suitable for high current handling
• Surface mount PCB installation for automated assembly
• Optimized for high current power supply circuits

Fixed Inductors Applications

• High current power supply filtering
• DC-DC converter output stages
• Industrial power management systems

Fixed Inductors Procurement Notes

Verify the specific ordering suffix and package configuration against the official manufacturer datasheet before procurement. Confirm that the RoHS compliance status meets project requirements. Ensure the selected supplier provides valid traceability documentation. Cross-reference the manufacturing date code to avoid obsolete stock. Validate that the component's thermal characteristics align with the final enclosure design constraints.

Fixed Inductors Selection Notes

Select this component when a 220 µH inductance value is required for high current applications up to 5 A. Consider the unshielded nature of the design regarding electromagnetic interference sensitivity in the target circuit layout. Evaluate the physical footprint of 27x23.5 mm against available PCB space. Compare the 50 mΩ DC resistance against efficiency requirements for the specific power stage.

Fixed Inductors Part Context

This part belongs to the 6000B series of surface mount power inductors manufactured by Murata Power Solutions. The series is characterized by wirewound technology and unshielded structures intended for robust high current performance. It falls under the broader category of SMD power inductors used in electronic power conversion and distribution systems.

Fixed Inductors Replacement Considerations

Consult the official Murata Power Solutions product selection guide for direct cross-references within the 6000B series. Verify compatibility with alternative suppliers offering similar 220 µH, 5 A unshielded SMD inductors. Ensure any substitute matches the 27x23.5x20 mm mechanical envelope and electrical parameters.

Fixed Inductors FAQ

Is the 60B224C inductor shielded?

No, the 60B224C is an unshielded power inductor.

What is the maximum DC current rating for this component?

The maximum DC current rating is 5 A.
