76385-413LF

Headers, Male Pins Overview

The Amphenol ICC (FCI) 76385-413LF is a Dubox series header connector featuring 26 positions in a dual-row configuration. It utilizes a 0.100-inch (2.54mm) pitch and is designed for right-angle through-hole mounting with solder termination. The contacts are gold-plated phosphor bronze, rated for 3A current at 300V. The housing is blue thermoplastic polyester, shrouded on two sides, ensuring polarized mating. Operating temperature ranges from -55°C to +125°C.

Headers, Male Pins Feature Summary

• Dual-row shrouded design provides secure alignment and prevents mis-mating during assembly.
• Gold-plated contacts ensure reliable signal transmission and corrosion resistance in harsh environments.
• Right-angle through-hole termination facilitates efficient PCB layout and space-constrained applications.

Headers, Male Pins Applications

• Industrial control systems requiring robust board-to-cable connections
• Telecommunications equipment infrastructure
• Automotive electronics modules

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to confirm contact plating and packaging type. Ensure the selected variant matches the required row count and pin configuration for your PCB footprint. Cross-reference the manufacturer's latest datasheet to confirm RoHS compliance and material specifications before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a high-density, dual-row connection is necessary for power or signal distribution. The 2.54mm pitch offers a balance between density and ease of handling. Consider the right-angle form factor for vertical interconnect needs where board space is limited horizontally.

Headers, Male Pins Part Context

This part belongs to the Dubox family of connectors, known for their versatility in board-to-board and board-to-wire applications. The series supports various configurations including single and dual rows with different termination styles, catering to diverse electronic assembly requirements across multiple industries.

Headers, Male Pins Replacement Considerations

Compatible substitutes include the 76385-413LF-GF-AU variant for gold-plated options or other Dubox headers with matching 26-position dual-row specifications. Verify mechanical dimensions and electrical ratings match exactly before substitution.

Headers, Male Pins FAQ

What is the insulation material used for the 76385-413LF?

The housing is made of thermoplastic polyester, which provides excellent thermal stability and mechanical strength.

Is this connector suitable for high-temperature environments?

Yes, it operates within a temperature range of -55°C to +125°C, making it suitable for demanding industrial conditions.
