77313-824-16LF

Headers, Male Pins Overview

The Amphenol ICC (FCI) 77313-824-16LF is a BergStik unshrouded header connector designed for board-to-board and wire-to-board applications. It features a 2.54 mm pitch with 16 positions arranged in a single row. The connector utilizes male pin contacts made of phosphor bronze, gold plated for reliable conductivity. It supports through-hole solder termination with a right-angle mounting style. The housing is constructed from black thermoplastic material rated UL 94 V-0 for flammability. Electrical specifications include a current rating of 3 A per contact and an insulation resistance of 5 GOhms. The operating temperature range spans from -65°C to +130°C.

Headers, Male Pins Feature Summary

• Right-angle unshrouded design facilitates dense board stacking and space-constrained layouts
• Gold-plated phosphor bronze contacts ensure stable signal transmission and corrosion resistance
• Thermoplastic housing provides mechanical stability and meets UL 94 V-0 flammability standards

Headers, Male Pins Applications

• Board-to-board interconnections in industrial control systems
• Wire-to-board connections in consumer electronics assemblies
• Signal routing in telecommunications equipment
• General-purpose interconnects in embedded computing modules

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix and RoHS compliance status directly with the manufacturer or authorized distributors before procurement. Confirm that the right-angle orientation and single-row configuration match the PCB footprint requirements. Ensure the gold plating thickness and contact material meet the intended electrical performance criteria for the application environment.

Headers, Male Pins Selection Notes

Select this component when a right-angle, single-row header with 2.54 mm pitch is required for through-hole assembly. The 16-position count suits moderate-density signal routing needs. Consider the 3 A current rating and thermal limits for power distribution tasks. Verify compatibility with mating female headers or cables to ensure proper engagement and mechanical retention.

Headers, Male Pins Part Context

This part belongs to the BergStik series by Amphenol ICC (formerly FCI), a widely used line of rectangular connectors. The series offers various position counts and configurations for diverse electronic interconnect needs. As an Amphenol product, it adheres to established quality and reliability standards for commercial and industrial electronics manufacturing.

Headers, Male Pins Replacement Considerations

Direct substitutes must maintain the 2.54 mm pitch, 16-position count, single-row layout, and right-angle through-hole termination. Compatible alternatives should feature similar gold-plated phosphor bronze contacts and thermoplastic housings. Verify mechanical dimensions and mating interface compatibility before cross-referencing with other manufacturers' offerings.
