850-10-038-40-001000

Headers, Male Pins Overview

The Mill-Max 850-10-038-40-001000 is a surface mount pin header connector designed for board-to-board applications. It features 38 positions arranged in a single row with a 0.050" (1.27mm) pitch. The connector utilizes gold-plated contacts and a black insulator made of polyamide (PA46). Rated for 1A current and 150VDC, it operates within a temperature range of -55°C to 125°C. The unit includes a push-pull locking mechanism and meets UL94 V-0 flammability standards.

Headers, Male Pins Feature Summary

• Surface mount construction for automated PCB assembly
• Gold-plated contacts for reliable signal transmission
• Push-pull locking mechanism for secure mating
• High-temperature resistant polyamide insulation

Headers, Male Pins Applications

• Board-to-board interconnections
• Electronic device internal wiring
• Industrial control systems
• Consumer electronics assemblies

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official Mill-Max documentation to confirm plating thickness and material variations. Ensure surface mount compatibility with your PCB footprint design. Cross-reference the datasheet for precise dimensional tolerances and reflow soldering profiles required for this component series.

Headers, Male Pins Selection Notes

Select this model for high-density single-row connections requiring surface mount technology. Consider the 1.27mm pitch for space-constrained designs. Evaluate the 1A current rating against system requirements. Confirm that the push-pull locking style aligns with mechanical retention needs compared to standard headers.

Headers, Male Pins Part Context

This component belongs to the Mill-Max 850 series of precision machined pin headers. The series offers various configurations including right-angle and vertical orientations. It is engineered for high-reliability interconnect solutions in demanding electronic environments, providing consistent performance across industrial and commercial applications.

Headers, Male Pins Replacement Considerations

Direct substitutes include other Mill-Max 850 series headers with matching 38-position counts and 1.27mm pitch. Verify equivalent surface mount capabilities and contact plating specifications when evaluating alternative part numbers from the same manufacturer family.
