Headers, Male Pins Overview

The Preci-Dip 852-10-006-10-001101 is a double-row pin header from the 852 series, featuring a 1.27 mm pitch and six contacts per row. Designed for through-hole mounting, it utilizes straight solder tails for secure PCB attachment. The connector supports a rated current of 1A and operates within a voltage range up to 150V DC. Constructed with brass contacts tin-plated for reliability, the housing is made of glass-filled thermoplastic. It functions as a male connector system suitable for board-to-board or cable-to-board applications in electronic assemblies.

Headers, Male Pins Feature Summary

• Double-row configuration with 1.27 mm spacing for high-density interconnects
• Straight through-hole solder tail design for robust mechanical fixation
• Tin-plated brass contacts ensuring stable electrical conductivity
• Glass-filled thermoplastic insulator providing thermal stability

Headers, Male Pins Applications

• Board-to-board interconnection systems
• Cable-to-board wiring harnesses
• General electronic circuit assembly
• Industrial control module interfaces

Headers, Male Pins Procurement Notes

Verify the specific part number against official Preci-Dip documentation to confirm contact count and row configuration. Ensure compatibility with mating female connectors regarding pitch and housing dimensions. Check for required surface finishes and temperature ratings relevant to the target application environment before finalizing procurement specifications.

Headers, Male Pins Selection Notes

Select this component when a double-row male header with 1.27 mm pitch is required for through-hole assembly. Consider the 1A current rating and 150V voltage limit for circuit design constraints. Verify that the straight orientation and solder tail termination align with the PCB layout and manufacturing process requirements.

Headers, Male Pins Part Context

This part belongs to the Preci-Dip 852 series, which offers various row counts and contact configurations. The series is characterized by its use of high-temperature thermoplastic insulators and standardized 1.27 mm spacing, making it a common choice for compact electronic designs requiring reliable vertical interconnections.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other 1.27 mm pitch double-row headers from manufacturers such as Samtec or Molex, provided they match the 6-pin per row configuration, through-hole mounting style, and similar electrical ratings.
