87052-120HLF

Headers, Male Pins Overview

The Amphenol ICC (FCI) 87052-120HLF is a BergStik unshrouded header connector designed for board-to-board applications. It features a vertical through-hole termination style with a 2.54 mm pitch and 20 positions arranged in a double-row configuration. The contacts are made of phosphor bronze with tin plating, rated for 3 A current and 1.5 kV voltage. The housing is constructed from thermoplastic material compliant with UL 94 V-0 flammability standards.

Headers, Male Pins Feature Summary

• Vertical through-hole mounting for secure PCB integration
• Double-row unshrouded design for high-density connections
• Tin-plated phosphor bronze contacts for reliable conductivity

Headers, Male Pins Applications

• Board-to-board interconnects
• Backplane systems
• General electronic equipment

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to ensure compatibility with mating connectors and PCB footprint requirements. Confirm that the tin-plated contact finish meets the environmental conditions of the target application. Check for any recent product change notices regarding material specifications or manufacturing locations before finalizing procurement plans.

Headers, Male Pins Selection Notes

Select this component when a vertical, double-row header with a standard 2.54 mm pitch is required. Ensure the PCB layout accommodates the 20-position double-row format. Verify that the 3 A current rating and 1.5 kV voltage rating align with the circuit design parameters. Consider the unshrouded nature of the connector for assembly clearance.

Headers, Male Pins Part Context

This part belongs to the BergStik series of headers and wire housings manufactured by Amphenol ICC (FCI). The series offers various position counts and row configurations for diverse connectivity needs. The 87052-120HLF specifically addresses applications requiring a 20-position vertical interface with robust mechanical and electrical performance characteristics.

Headers, Male Pins Replacement Considerations

Compatible substitutes within the same series include 87052-406HLF and 87052-430HLF, which share similar structural designs but differ in position count.
