929834-04-22-RK

$2.27

Description：CONN HEADER VERT 22POS 2.54MM
Series：929
Mfr：3M
Package：Bulk

SKU:bc34c59e9d47 Category: Headers, Male Pins Brand: 3M

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

929834-04-22-RK is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists 3M. Its product description is CONN HEADER VERT 22POS 2.54MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for 929834-04-22-RK

Description：CONN HEADER VERT 22POS 2.54MM
Series：929
Mfr：3M
Package：Bulk
Connector Type：Header, Breakaway
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：22
Number of Rows：1
Row Spacing - Mating：-
Number of Positions Loaded：All
Style：Board to Board
Shrouding：Unshrouded
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.235" (5.97mm)
Contact Length - Post：0.510" (12.95mm)
Overall Contact Length：0.845" (21.46mm)
Insulation Height：0.100" (2.54mm)
Contact Shape：Square
Contact Finish - Mating：Tin
Contact Finish Thickness - Mating：200.0µin (5.08µm)
Contact Finish - Post：Tin
Contact Material：Copper Alloy
Insulation Material：Polycyclohexylenedimethylene Terephthalate (PCT)
Features：-
Operating Temperature：-40°C ~ 105°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：2.5A
Voltage Rating：-

Headers, Male Pins datasheet and documents for 929834-04-22-RK

929834-04-22-RK

Headers, Male Pins Overview

The 3M 929834-04-22-RK is a single-row pin strip header connector from the 929 Series, featuring 22 positions with a 2.54 mm (0.100 inch) pitch. Designed for through-hole mounting, it utilizes copper alloy contacts with tin plating and a black PBT insulator rated UL94 V-0. The component supports a current rating of 2.5 A and a voltage rating of 1.5 kV, operating within a temperature range of -40°C to 105°C. It has a straight installation angle and square contact shape.

Headers, Male Pins Feature Summary

Single-row male pin configuration for board-to-board interconnection
Through-hole solder termination with straight mounting style
High dielectric strength insulation material rated for 1.5 kV

Headers, Male Pins Applications

General electronic circuit board interconnections
Industrial control system wiring harnesses
Test and measurement equipment interfaces

Headers, Male Pins Procurement Notes

Verify RoHS compliance status carefully as datasheets indicate non-compliance for this specific part number variant. Confirm lead times due to potential discontinuation or limited availability across distributors. Ensure procurement channels provide valid manufacturer documentation to verify electrical ratings and material specifications before integration into production designs.

Headers, Male Pins Selection Notes

Select this component when a single-row male header with 22 pins and 2.54 mm spacing is required. Verify that the 2.5 A current rating and 1.5 kV voltage withstand capability meet circuit requirements. Ensure PCB layout accommodates the specified through-hole dimensions and straight orientation for proper mating with compatible socket housings.

Headers, Male Pins Part Context

This connector belongs to the 3M 929 Series, a line of rectangular headers designed for reliable signal and power transmission. The series offers various pin counts and row configurations to support diverse electronic assembly needs. The 929834 base model indicates a specific pin strip header format within this broader product family.
