A-WBP-K002DG-40TB01

Headers, Male Pins Overview

The A-WBP-K002DG-40TB01 is a wire-to-board connector header manufactured by Assmann WSW Components. It features a through-hole mounting style with two rows and forty positions. The pitch spacing between contacts is 0.079 inches (2.00mm). The component utilizes male pin contact types for secure electrical interfacing. It is designed to operate within a temperature range of -40°C to 105°C, ensuring reliability under varying thermal conditions.

Headers, Male Pins Feature Summary

• Board to cable/wire connection style
• Through-hole mounting configuration
• Male pin contact type

Headers, Male Pins Applications

• General electronic interconnections
• Consumer electronics assemblies
• Industrial control panels

Headers, Male Pins Procurement Notes

Verify the specific part number against official manufacturer documentation to ensure compatibility with existing board layouts and mating connectors. Confirm that the through-hole footprint matches the design specifications. Check for any updated environmental compliance certifications required for the target application region before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a 2.00mm pitch header with forty positions is required for wire-to-board applications. Ensure the operating temperature range meets the environmental demands of the end product. Verify that the mechanical locking mechanism aligns with the assembly process requirements.

Headers, Male Pins Part Context

This part belongs to the A-WBP series of wafer connectors from Assmann WSW Components. The series offers various position counts and pitch options to suit different connectivity needs. The K002DG suffix indicates specific material and contact plating characteristics defined by the manufacturer.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 2.00mm pitch, 40-position count, and dual-row configuration. Verify mechanical dimensions and electrical ratings before swapping components.
