A-WBP-L004EG-09SR01

Headers, Male Pins Overview

The A-WBP-L004EG-09SR01 is a surface mount connector header manufactured by Assmann WSW Components. It features a 9-position configuration with a 2.50 mm (0.098 inch) pitch. The component is designed for board-to-wire applications, utilizing a wafer-style header construction. This specific part number identifies the surface mount variant within the manufacturer's wire-to-board series.

Headers, Male Pins Feature Summary

• Surface mount technology design for automated PCB assembly
• 9-position layout with standardized 2.50 mm spacing
• Wafer-style header construction for secure wire termination

Headers, Male Pins Applications

• Board-to-wire interconnections in electronic assemblies
• Signal and power distribution in consumer electronics
• Industrial control module wiring interfaces

Headers, Male Pins Procurement Notes

Verify the surface mount orientation and pin count against the target PCB footprint. Confirm that the 2.50 mm pitch matches the design requirements. Ensure the supplier provides traceability documentation for RoHS compliance. Check for any specific handling instructions regarding thermal sensitivity during reflow soldering processes.

Headers, Male Pins Selection Notes

Select this component when a low-profile surface mount header is required for 9-wire connections. The 2.50 mm pitch offers a balance between density and ease of manual wiring if necessary. Consider the mechanical stability provided by the surface mount pads compared to through-hole alternatives for vibration resistance.

Headers, Male Pins Part Context

This part belongs to Assmann WSW's wire-to-board connector portfolio, specifically the surface mount header category. It complements other variants in the series that may differ in mounting style or contact quantity. The product serves as a critical interface element for connecting flexible flat cables or individual wires to rigid circuit boards.

Headers, Male Pins Replacement Considerations

Direct substitutes must maintain the 9-position count and 2.50 mm pitch. Verify that alternative suppliers offer identical surface mount terminal geometries. Cross-reference mechanical dimensions to ensure compatibility with existing PCB silkscreen and copper pad layouts.
