AA3528QBS/D09

LED Indication - Discrete Overview

The AA3528QBS/D09 is a single-color blue surface-mount LED manufactured by Kingbright. It features a 1311 (3228 metric) package with dimensions of 3.5 mm length, 2.8 mm width, and 1.9 mm height. The component emits light at a peak wavelength of 460 nm with a water clear round flat lens. Key electrical parameters include a forward current of 20 mA, a forward voltage of 3.3 V, and a power rating of 120 mW. It offers a luminous intensity of 150 mcd and a viewing angle of 120 degrees. The device operates within a temperature range of -40°C to +85°C.

LED Indication - Discrete Feature Summary

• Emits blue light at a 460 nm peak wavelength
• Utilizes a water clear round flat lens for optical transmission
• Designed for surface mount technology installation
• Supports standard 20 mA forward current operation

LED Indication - Discrete Applications

• Indicator lighting in electronic devices
• Backlighting applications requiring blue illumination
• Panel status indication systems

LED Indication - Discrete Procurement Notes

Verify the specific suffix D09 against manufacturer documentation to confirm exact binning or packaging variations. Ensure compatibility with moisture sensitivity levels during storage and handling. Cross-reference the 1311 package footprint with PCB layout requirements before integration.

LED Indication - Discrete Selection Notes

Select this component when a compact blue SMD LED with moderate intensity is required. Consider the 3.3 V forward voltage drop for circuit design. Evaluate the 120-degree viewing angle against optical coverage needs. Confirm thermal management capabilities for the specified operating temperature range.

LED Indication - Discrete Part Context

This part belongs to Kingbright's single-color LED portfolio, specifically within the blue LED category. It shares the standard 3528 form factor family but differs in color and electrical characteristics from other variants like red or green models. The D09 suffix denotes specific manufacturing attributes defined by the supplier.

LED Indication - Discrete Replacement Considerations

Public confirmed substitute part numbers are not available in the provided source material. Verify pinout and dimensional tolerances if considering alternative manufacturers' blue LEDs.
