AAA3528SURKCGKC09

$0.56

Description：LED GRN/RED CLEAR SMD BOTTOM ENT
Series：Heli-R
Mfr：Kingbright
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:e2c12b8f0dcd Category: LED Indication - Discrete Brand: Kingbright

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

AAA3528SURKCGKC09 is listed in the LED Indication - Discrete range at ChipApex. The manufacturer field lists Kingbright. Its product description is LED GRN/RED CLEAR SMD BOTTOM ENT. Review the specifications below when checking this part for your BOM.

LED Indication - Discrete specifications for AAA3528SURKCGKC09

Description：LED GRN/RED CLEAR SMD BOTTOM ENT
Series：Heli-R
Mfr：Kingbright
Package：Tape & Reel (TR),Cut Tape (CT)
Color：Green, Red
Configuration：Independent
Lens Color：Colorless
Lens Transparency：Clear
Millicandela Rating：80mcd Green, 100mcd Red
Lens Style：Round with Flat Top
Lens Size：2.40mm Dia
Voltage - Forward (Vf) (Typ)：2.1V Green, 1.95V Red
Current - Test：20mA Green, 20mA Red
Viewing Angle：120°
Mounting Type：Surface Mount, Bottom Entry
Wavelength - Dominant：570nm Green, 630nm Red
Wavelength - Peak：574nm Green, 645nm Red
Features：-
Package / Case：4-SMD, Gull Wing
Supplier Device Package：SMD
Size / Dimension：3.20mm L x 2.80mm W
Height (Max)：2.10mm
Grade：-
Qualification：-

LED Indication - Discrete datasheet and documents for AAA3528SURKCGKC09

AAA3528SURKCGKC09

LED Indication - Discrete Overview

The AAA3528SURKCGKC09 is a bi-color surface-mount LED from Kingbright, featuring red and green emission within a 1411 (3528 metric) package. It utilizes a round flat lens with water clear transparency. The component operates at a forward current of 20 mA for both colors. Electrical parameters include a forward voltage of 1.95 V for the red element and 2.1 V for the green element. Peak wavelengths are specified at 645 nm for red and 574 nm for green. The device supports an operating temperature range from -40 C to +85 C.

LED Indication - Discrete Feature Summary

Bi-color configuration enabling independent red and green light emission within a single compact SMD footprint.
Water clear round flat lens design provides consistent optical transmission and visual appearance.

LED Indication - Discrete Applications

Status indication in electronic equipment requiring dual-state signaling.
Indicator lights for control panels and user interface devices.
Visual alerts in automotive or industrial instrumentation systems.

LED Indication - Discrete Procurement Notes

Verify RoHS compliance status through official manufacturer documentation prior to integration. Confirm moisture sensitivity level handling requirements during storage and assembly processes. Ensure thermal management aligns with the specified maximum operating temperature limits. Cross-reference datasheet electrical characteristics against circuit design constraints.

LED Indication - Discrete Selection Notes

Select this component when a dual-color indicator is required in a standard 3528 form factor. Consider the specific wavelength outputs for visibility requirements in target environments. Evaluate the forward voltage differences between red and green channels for driver circuit compatibility. Assess mechanical mounting constraints relative to the surface mount package dimensions.

LED Indication - Discrete Part Context

This part belongs to Kingbright's bi-color LED series designed for surface mount technology applications. It shares dimensional similarities with other components in the 3528 family but offers distinct dual-emission capabilities. The product line focuses on providing reliable visual feedback solutions for modern electronic assemblies.
