Product Detailed Parameters
- Description：LED RGB CLEAR 6SMD
- Series：HELI Colour
- Mfr：Kingbright
- Package：Tape & Reel (TR)
- Color：Red, Green, Blue (RGB)
- Configuration：Independent
- Lens Color：Colorless
- Lens Transparency：Clear
- Millicandela Rating：60mcd Red, 180mcd Green, 30mcd Blue
- Lens Style：Square with Flat Top
- Lens Size：2.44mm
- Voltage - Forward (Vf) (Typ)：1.8V Red, 2.7V Green, 2.7V Blue
- Current - Test：2mA Red, 2mA Green, 2mA Blue
- Viewing Angle：120°
- Mounting Type：Surface Mount
- Wavelength - Dominant：625nm Red, 525nm Green, 465nm Blue
- Wavelength - Peak：640nm Red, 515nm Green, 460nm Blue
- Features：-
- Package / Case：6-PLCC
- Supplier Device Package：6-SMD
- Size / Dimension：3.20mm L x 2.80mm W
- Height (Max)：1.85mm
- Grade：-
- Qualification：-
Download product information
Overview
The AAAF3529LSEKJ3ZGKQBS is a multi-color surface-mount LED from Kingbright, featuring an RGB configuration within a 3.5x2.8mm package. It operates with low current requirements and utilizes a water-clear lens for optimal light transmission. The component supports a wide operating temperature range from -40°C to +85°C and includes moisture sensitivity protection. Key electrical parameters include forward voltages of approximately 2.2V, 3.3V, and 3.3V for the respective colors, with a maximum power rating of 140mW.
Feature Summary
- Integrates Red, Green, and Blue chips into a single compact SMD package for full-color indication.
- Designed for low-current operation to enhance energy efficiency in dense circuit designs.
- Features a water-clear lens with a 120-degree viewing angle for broad visibility.
Applications
- Status indication on electronic control panels
- Backlighting for small form-factor devices
- Consumer electronics status indicators
Procurement Notes
Verify the specific suffix against the manufacturer's latest datasheet to confirm exact binning and optical characteristics. Ensure compatibility with reflow soldering profiles specified in the official documentation. Check for moisture sensitivity level (MSL) handling requirements prior to assembly to prevent package damage during manufacturing processes.
Selection Notes
Select this component when space constraints require a compact RGB solution with low power consumption. The 3.5x2.8mm footprint offers a balance between size and luminous intensity compared to larger packages. Consider the low-current specification for battery-operated applications where power efficiency is critical for extended operational life.
Part Context
This part belongs to Kingbright's HeliColour series, which focuses on high-reliability multi-color LEDs. The series is engineered for modern surface-mount technology applications requiring precise color mixing and consistent performance across various environmental conditions.
Replacement Considerations
Direct substitutes may include other Kingbright RGB LEDs in similar 3528 or 3228 footprints, such as the AAAF3529SEKJ3ZGKQBKS, provided pinout and electrical specifications match the design requirements.
