AD8513ARUZ

$11.17

Description：IC OPAMP JFET 4 CIRCUIT 14TSSOP
Series：-
Mfr：Analog Devices Inc.
Package：Tube

SKU:ca606e9b0b57 Category: Instrumentation, Op Amps, Buffer Amps Brand: Analog Devices Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

AD8513ARUZ is listed in the Instrumentation, Op Amps, Buffer Amps range at ChipApex. The manufacturer field lists Analog Devices Inc.. Its product description is IC OPAMP JFET 4 CIRCUIT 14TSSOP. Review the specifications below when checking this part for your BOM.

Instrumentation, Op Amps, Buffer Amps specifications for AD8513ARUZ

Description：IC OPAMP JFET 4 CIRCUIT 14TSSOP
Series：-
Mfr：Analog Devices Inc.
Package：Tube
Amplifier Type：J-FET
Number of Circuits：4
Output Type：-
Slew Rate：20V/µs
Gain Bandwidth Product：8 MHz
Current - Input Bias：25 pA
Voltage - Input Offset：100 µV
Current - Supply：2.2mA (x4 Channels)
Current - Output / Channel：70 mA
Voltage - Supply Span (Min)：10 V
Voltage - Supply Span (Max)：30 V
Operating Temperature：-40°C ~ 125°C
Grade：-
Qualification：-
Mounting Type：Surface Mount
Package / Case：14-TSSOP (0.173", 4.40mm Width)
Supplier Device Package：14-TSSOP
-3db Bandwidth：-

Instrumentation, Op Amps, Buffer Amps datasheet and documents for AD8513ARUZ

AD8513ARUZ

Instrumentation, Op Amps, Buffer Amps Overview

The AD8513ARUZ is a quad precision JFET operational amplifier from Analog Devices. It features an 8 MHz gain bandwidth product, a 20 V/µs slew rate, and a maximum offset voltage of 400 µV. The device operates on dual supplies ranging from ±5 V to ±15 V with a supply current of approximately 2.75 mA per amplifier. It utilizes a 14-lead SOIC_N package and maintains stability when driving capacitive loads.

Instrumentation, Op Amps, Buffer Amps Feature Summary

Maintains fast settling performance even with substantial capacitive loads
Prevents output phase reversal when input voltages exceed the common-mode range
Provides low noise and distortion suitable for high-fidelity audio applications

Instrumentation, Op Amps, Buffer Amps Applications

Instrumentation systems
Multipole filters
Photodiode amplifiers
Precision current measurement using shunts

Instrumentation, Op Amps, Buffer Amps Procurement Notes

Verify the specific ordering suffix against the manufacturer's official documentation to confirm the exact package type and reel specifications. Confirm that the component meets all required environmental operating temperature ranges before finalizing procurement decisions.

Instrumentation, Op Amps, Buffer Amps Selection Notes

Select this component for circuits requiring high impedance sensor amplification and precise current measurements. The combination of low offsets, low noise, and very low input bias currents makes it ideal for maintaining accuracy in medical instruments and automated test equipment.

Instrumentation, Op Amps, Buffer Amps Part Context

This part belongs to the AD8510/AD8512/AD8513 family of precision JFET amplifiers. While the AD8510 is single-channel and the AD8512 is dual-channel, the AD8513 integrates four independent amplifiers into a single package, sharing identical electrical characteristics and performance metrics across the series.
