AG30P-5

AG30P-5 is listed in the DC DC Converters range at ChipApex. The manufacturer field lists XP Power. Its product description is DC DC CONVERTER 3000V 1W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for AG30P-5

• Description：DC DC CONVERTER 3000V 1W
• Series：XP EMCO - AG (1W)
• Mfr：XP Power
• Package：Box
• Type：High Voltage - Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：0.7V
• Voltage - Input (Max)：5V
• Voltage - Output 1：3000V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：330µA
• Power (Watts)：1 W
• Voltage - Isolation：500 V
• Applications：ITE (Commercial)
• Features：Proportional Output
• Operating Temperature：-25°C ~ 75°C
• Efficiency：-
• Mounting Type：Surface Mount
• Package / Case：5-SMD Module
• Size / Dimension：1.13" L x 0.45" W x 0.25" H (28.7mm x 11.4mm x 6.4mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：-
• Standard Number：62368-1
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for AG30P-5
