AM12TW-4805SZ

AM12TW-4805SZ is listed in the DC DC Converters range at ChipApex. The manufacturer field lists aimtec. Its product description is DC DC CONVERTER 5.1V 12W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for AM12TW-4805SZ

• Description：DC DC CONVERTER 5.1V 12W
• Series：AM12TW-Z (12W)
• Mfr：aimtec
• Package：Tube
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：18V
• Voltage - Input (Max)：75V
• Voltage - Output 1：5.1V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：2.4A
• Power (Watts)：12 W
• Voltage - Isolation：1.6 kV
• Applications：ITE (Commercial)
• Features：Remote On/Off
• Operating Temperature：-40°C ~ 85°C
• Efficiency：89%
• Mounting Type：Through Hole
• Package / Case：24-DIP Module
• Size / Dimension：1.25" L x 0.80" W x 0.42" H (31.8mm x 20.3mm x 10.7mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：CE, UL
• Standard Number：-
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for AM12TW-4805SZ
