AM1DS-0315SH30EZ

AM1DS-0315SH30EZ is listed in the DC DC Converters range at ChipApex. The manufacturer field lists aimtec. Its product description is DC/DC Converter 15V 1W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for AM1DS-0315SH30EZ

• Description：DC/DC Converter 15V 1W
• Series：AM1DS-EZ (1W)
• Mfr：aimtec
• Package：Tube
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：2.97V
• Voltage - Input (Max)：3.63V
• Voltage - Output 1：15V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：67mA
• Power (Watts)：1 W
• Voltage - Isolation：3 kV
• Applications：ITE (Commercial)
• Features：-
• Operating Temperature：-40°C ~ 105°C (With Derating)
• Efficiency：84%
• Mounting Type：Through Hole
• Package / Case：7-SIP Module, 4 Leads
• Size / Dimension：0.77" L x 0.24" W x 0.39" H (19.5mm x 6.0mm x 10.0mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：CE, UL
• Standard Number：62368-1
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for AM1DS-0315SH30EZ
