APA2106PBC/A

Description：LED BLUE CLEAR SMD R/A
Series：-
Mfr：Kingbright
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:e0847637181c Category: LED Indication - Discrete Brand: Kingbright

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：LED BLUE CLEAR SMD R/A
Series：-
Mfr：Kingbright
Package：Tape & Reel (TR),Cut Tape (CT)
Color：Blue
Configuration：Standard
Lens Color：Colorless
Lens Transparency：Clear
Millicandela Rating：60mcd
Lens Style：Rectangle with Domed Top
Lens Size：1.70mm x 0.60mm
Voltage - Forward (Vf) (Typ)：3.2V
Current - Test：20mA
Viewing Angle：120°
Mounting Type：Surface Mount, Right Angle
Wavelength - Dominant：470nm
Wavelength - Peak：468nm
Features：-
Package / Case：2-SMD, No Lead
Supplier Device Package：SMD
Size / Dimension：2.10mm L x 1.00mm W
Height (Max)：0.60mm
Grade：-
Qualification：-

Download product information

APA2106PBC/A

Overview

The Kingbright APA2106PBC/A is a single-color blue surface-mount LED featuring a water-clear lens. It operates with a forward voltage of 4V and emits light at a peak wavelength of 468nm. The component has a maximum continuous forward current rating of 30mA and a power dissipation limit of 120mW. It offers a nominal luminous intensity of 40mcd at 20mA with a wide viewing angle of 120 degrees. The device measures 2.10mm by 0.60mm with a height of 1mm, designed for standard SMT processes.

Feature Summary

Utilizes InGaN technology for efficient blue light emission
Features a compact 2.1x0.6mm surface-mount package
Provides a wide 120-degree viewing angle
Compliant with RoHS standards

Applications

Panel indicators
Backlighting applications
General-purpose electronic equipment status indication

Procurement Notes

Verify the specific suffix 'A' against the manufacturer datasheet to confirm lens type and binning specifications. Ensure compatibility with moisture sensitivity level requirements during storage and reflow soldering. Confirm that the 30mA maximum forward current aligns with the target circuit design thermal management capabilities.

Selection Notes

Select this component when a low-profile blue indicator is required for space-constrained designs. The 120-degree viewing angle makes it suitable for applications requiring broad visibility. Verify that the 4V forward voltage drop is compatible with the available drive voltage in the system architecture.

Part Context

This part belongs to the Kingbright 2106 series of surface-mount LEDs. The series includes various colors and lens configurations within the same 2.1x0.6mm footprint. The APA2106PBC/A specifically denotes the blue variant with a water-clear lens and standard mounting characteristics.

Replacement Considerations

Direct substitutes include other Kingbright parts from the 2106 series such as APA2106QBC/D or APA2106VBC/D, provided the color and intensity specifications meet the design requirements. Cross-manufacturer replacements must match the 2.1x0.6mm outline and electrical parameters.
