APG0603RWF-TT-5MAV

LED Indication - Discrete Overview

The APG0603RWF-TT-5MAV is a single-color surface-mount LED manufactured by Kingbright, designed for compact electronic applications. It features a rectangular lens with diffused transparency and emits red light. The component operates within a temperature range of -40°C to +85°C and has a maximum power rating of 120 mW. It utilizes a standard SMD/SMT mounting style suitable for automated assembly processes.

LED Indication - Discrete Feature Summary

• Rectangular lens shape with diffused transparency for optimized light distribution
• Designed for high-reliability surface-mount technology integration
• Operates effectively across a wide industrial temperature spectrum

LED Indication - Discrete Applications

• Indicator lights in consumer electronics devices
• Status signaling in medical instrumentation
• Visual feedback components in automotive control panels

LED Indication - Discrete Procurement Notes

Verify the specific suffix configuration against the official Kingbright datasheet to ensure compatibility with required forward current and voltage parameters. Confirm RoHS compliance status and moisture sensitivity level prior to procurement. Check for any product change notifications that may affect electrical characteristics or physical dimensions.

LED Indication - Discrete Selection Notes

Select this component when a low-profile red indicator is required for space-constrained designs. Ensure the driving circuit supports the specified forward current without exceeding the 120 mW power rating. Consider the diffused lens properties if uniform illumination is preferred over focused beam output.

LED Indication - Discrete Part Context

This part belongs to Kingbright's APG series of ultra-thin SMD LEDs, which are engineered for high-density PCB layouts. The series offers various color options and lens configurations to meet diverse visual indication requirements in modern miniaturized electronic systems.

LED Indication - Discrete Replacement Considerations

Consult the official Kingbright cross-reference list for verified substitutes. Generic replacements may differ in luminous intensity or viewing angle specifications.
