APHCM2012CGCK-F01

$0.23

Description：LED GREEN CLEAR CHIP SMD
Series：-
Mfr：Kingbright
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:e3d52b705697 Category: LED Indication - Discrete Brand: Kingbright

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：LED GREEN CLEAR CHIP SMD
Series：-
Mfr：Kingbright
Package：Tape & Reel (TR),Cut Tape (CT)
Color：Green
Configuration：Standard
Lens Color：Colorless
Lens Transparency：Clear
Millicandela Rating：50mcd
Lens Style：Rectangle with Flat Top
Lens Size：1.30mm x 1.25mm
Voltage - Forward (Vf) (Typ)：2.1V
Current - Test：20mA
Viewing Angle：110°
Mounting Type：Surface Mount
Wavelength - Dominant：570nm
Wavelength - Peak：574nm
Features：-
Package / Case：0805 (2012 Metric)
Supplier Device Package：Chip LED
Size / Dimension：2.00mm L x 1.25mm W
Height (Max)：0.40mm
Grade：-
Qualification：-

Download product information

APHCM2012CGCK-F01

Overview

The Kingbright APKCM2012CGCK-F01 is a surface-mount LED indicator from the KPHCM-2012 series. It features a green light emission with a peak wavelength of 570nm and a clear, colorless lens. The component operates at a forward voltage of 2.5V and supports a maximum forward current of 150mA. It provides a luminous intensity of 230 mcd with a viewing angle of 110 degrees. The package dimensions are 2.0mm by 1.2mm, with a total height of 1.3mm. It dissipates up to 75mW of power and complies with RoHS standards.

Feature Summary

Green light emission with high visibility
Surface-mount technology for automated assembly
Clear lens design for optimal light transmission
RoHS compliant construction

Applications

PCB status indication
Electronic device power indicators
Control panel signaling

Procurement Notes

Verify the exact part number suffix against official Kingbright documentation to ensure correct binning and optical characteristics. Confirm that the specified package dimensions and pin configuration match your PCB footprint requirements. Check for any recent product change notifications that may affect material composition or manufacturing location. Ensure compliance with local environmental regulations regarding RoHS certification before finalizing procurement orders.

Selection Notes

Select this component when a compact green surface-mount LED is required for space-constrained designs. The 2012 package size offers a balance between light output and board real estate. Consider the 110-degree viewing angle for applications requiring broad visibility. Verify that the 2.5V forward voltage aligns with your circuit's drive capabilities and current limiting resistor calculations.

Part Context

This part belongs to Kingbright's KPHCM-2012 series of surface-mount LEDs. The series includes various colors such as red, yellow, and green in the same physical package. These components are designed for general-purpose indication on printed circuit boards. The family emphasizes reliability and consistent optical performance across different wavelengths.

Replacement Considerations

Direct substitutes within the same package include other colors from the KPHCM-2012 series, such as APKCM2012SURCK-F01 (Red) or APKCM2012SYCK-F01 (Yellow). Cross-referencing with other manufacturers requires verifying identical electrical parameters and mechanical dimensions.
