APL3015QGC

$0.34

Description：3.0X1.5MM,GRN SMD LED
Series：-
Mfr：Kingbright
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:e3b7c8e27cf6 Category: LED Indication - Discrete Brand: Kingbright

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

APL3015QGC is listed in the LED Indication - Discrete range at ChipApex. The manufacturer field lists Kingbright. Its product description is 3.0X1.5MM,GRN SMD LED. Review the specifications below when checking this part for your BOM.

LED Indication - Discrete specifications for APL3015QGC

Description：3.0X1.5MM,GRN SMD LED
Series：-
Mfr：Kingbright
Package：Tape & Reel (TR),Cut Tape (CT)
Color：Green
Configuration：Independent
Lens Color：Colorless
Lens Transparency：Clear
Millicandela Rating：20mcd
Lens Style：Rectangle with Flat Top
Lens Size：2.00mm x 1.50mm
Voltage - Forward (Vf) (Typ)：2.15V
Current - Test：20mA
Viewing Angle：70°
Mounting Type：Surface Mount
Wavelength - Dominant：565nm
Wavelength - Peak：560nm
Features：-
Package / Case：2-SMD, No Lead
Supplier Device Package：2-SMD
Size / Dimension：3.00mm L x 1.50mm W
Height (Max)：1.60mm
Grade：-
Qualification：-

LED Indication - Discrete datasheet and documents for APL3015QGC

APL3015QGC

LED Indication - Discrete Overview

The Kingbright APL3015QGC is a single-color surface-mount LED emitting green light. It utilizes a water-clear semitube lens to direct illumination with a viewing angle of 70 degrees. The component operates within a temperature range of -40°C to +85°C and features a rectangular lens shape. Electrical characteristics include a forward current of 20 mA, a forward voltage of 2.15 V, and a power rating of 105 mW. The peak wavelength is 565 nm, and the luminous intensity is rated at 20 mcd.

LED Indication - Discrete Feature Summary

Emits green light through a water-clear semitube lens
Designed for surface-mount technology installation
Operates reliably across extended industrial temperature ranges

LED Indication - Discrete Applications

Electronic equipment status indicators
Control panel illumination
General-purpose visual signaling devices

LED Indication - Discrete Procurement Notes

Verify the specific suffix against official Kingbright documentation to confirm exact binning and optical specifications. Ensure compatibility with moisture sensitivity levels during storage and handling. Confirm RoHS compliance status directly from the manufacturer's datasheet before integration into regulated assemblies.

LED Indication - Discrete Selection Notes

Select this component when a compact green indicator is required for space-constrained printed circuit boards. Consider the 70-degree viewing angle and 20 mcd intensity for standard visibility requirements. Evaluate thermal management needs based on the specified maximum operating temperature and power dissipation limits.

LED Indication - Discrete Part Context

This part belongs to the Kingbright APL series of single-color LEDs. These components are engineered for high-reliability surface-mount applications. The series offers various color options and lens configurations to suit diverse electronic design requirements.
