AVP6014R

Overview

The AVP6014R is a LAN discrete module manufactured by Pulse Electronics, designed for high-speed data transmission applications. This component supports 2.5 Gigabit Ethernet (2.5G) over a single port with four pairs of wiring. It is engineered to handle Power over Ethernet (PoE) standards up to 60W, ensuring stable power delivery alongside data signals. The module utilizes surface-mount technology (SMD/SMT) for automated assembly integration. Key electrical specifications include an isolation voltage rating of 1.5 kVrms and a defined frequency range starting at 100 kHz. The device operates within a temperature range of -40°C to +70°C, providing reliable performance in various industrial and commercial environments.

Feature Summary

• Supports 2.5G Ethernet data rates for enhanced network throughput
• Capable of delivering up to 60W Power over Ethernet (PoE)
• Provides 1.5 kVrms isolation voltage for signal safety
• Designed for surface-mount installation on printed circuit boards

Applications

• High-performance wired network infrastructure equipment
• Industrial automation systems requiring robust PoE connectivity
• Smart building IoT devices needing combined power and data links
• Commercial access points supporting advanced Ethernet standards

Procurement Notes

Verify the specific datasheet version and RoHS compliance status directly with Pulse Electronics or authorized distributors before procurement. Ensure that the ordering suffix matches the required packaging format, such as cut tape or reel, as these may affect handling procedures. Confirm that the supplier provides genuine components with traceable origin to maintain quality assurance standards. Cross-reference the part number against official manufacturer databases to avoid counterfeit risks. Validate that the component meets all relevant regulatory requirements for the target market.

Selection Notes

Select the AVP6014R when designing circuits that require 2.5G Ethernet capabilities integrated with significant PoE power delivery up to 60W. Consider this module for space-constrained designs due to its surface-mount package form factor. Evaluate the thermal management requirements based on the specified operating temperature range of -40°C to +70°C. Ensure compatibility with the system's isolation voltage needs, given the 1.5 kVrms rating. Compare physical dimensions against available PCB real estate to confirm fitment without interference from adjacent components.

Part Context

The AVP6014R belongs to the LAN Discrete Modules category within Pulse Electronics' portfolio. It is specifically categorized under Audio & Signal Transformers and Transformers subcategories. The product is part of the broader family of networking components designed for modern Ethernet standards. Pulse Electronics manufactures this component to meet the increasing demand for higher bandwidth and power delivery in connected devices. The module serves as a critical interface between network cables and electronic circuitry.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Consult official manufacturer resources for direct replacements or pin-compatible alternatives.
