B132R

Antennas RF Overview

The TE Connectivity B132R is a discontinued mobile coil antenna designed for VHF applications. It operates within a frequency range of 132MHz to 525MHz, with a center frequency of 153MHz. The component features a straight whip design and provides a gain of 3dBi. It utilizes an NMO base mount for installation. The antenna incorporates a tuning chrome elastomer spring package to enhance flexibility and shape retention under mechanical stress.

Antennas RF Feature Summary

• Incorporates a tuning chrome elastomer spring package for improved mechanical flexibility and durability in mobile environments.
• Features a straight whip antenna design optimized for VHF radio frequency transmission and reception.
• Equipped with an NMO base mount for secure and standardized vehicle installation.

Antennas RF Applications

• Mobile station communication systems
• VHF radio frequency applications
• Vehicle-mounted antenna installations

Antennas RF Procurement Notes

This component has been officially declared obsolete by the manufacturer as of November 2024. Procurement is no longer possible through standard manufacturing channels. Verification of current availability should focus on surplus distributors or secondary market sources, noting that stock levels are subject to change and may be limited.

Antennas RF Selection Notes

Designers must account for the discontinuation status when selecting this part. The primary consideration is identifying a suitable replacement from the same product family, such as the B1323S, which shares similar mounting and functional characteristics. Ensure that any substitute meets the required frequency range and mechanical interface specifications for the intended application.

Antennas RF Part Context

The B132R belongs to the Mobile Coil Antennas series, specifically utilizing elastomer spring packages. This series is engineered for robust performance in mobile environments where vibration and movement are prevalent. The component represents a legacy solution for VHF mobile communications before being superseded by newer iterations in the product line.

Antennas RF Replacement Considerations

The B1323S is identified as a similar replacement part manufactured by TE Connectivity. Engineers should verify that the B1323S meets all electrical and mechanical requirements of the original design before substitution.

Antennas RF FAQ

What is the operating frequency range of the B132R?

The B132R operates within a frequency range of 132MHz to 525MHz.

Is the B132R currently available for new production?

No, the B132R is obsolete and no longer manufactured as of November 2024.
